M5Stack Goplus2 DC Motor and Servo Driver Module (STM32F0)
M5Stack Goplus2 DC Motor and Servo Driver Module (STM32F0)
M5Stack GoPlus2 is a stackable multi-functional motor and servo control module. The master control integrates the STM32F030C8T6 chipset. The module is equipped with a 2-way DC motor drive interface and a 4-way servo drive interface. Three PORT-B interfaces(Analog Input, Digital Output, Digital Input) can be expanded. Built-in 500mAh battery and support infrared (IR) transmission and reception. In order to meet the requirements of a multi-channel interface power supply at the same time, a DC power interface is provided for external power supply, the battery can be charged through the M5Core with USB-C.
Communication protocol: I2C(0x38)
Applications:
- Actuator / motor driver
- Acquisition and control of multiple input and output signals
- Infrared controller
- DIY Toy base
Original: $26.01
-70%$26.01
$7.80Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
M5Stack Goplus2 DC Motor and Servo Driver Module (STM32F0)
M5Stack GoPlus2 is a stackable multi-functional motor and servo control module. The master control integrates the STM32F030C8T6 chipset. The module is equipped with a 2-way DC motor drive interface and a 4-way servo drive interface. Three PORT-B interfaces(Analog Input, Digital Output, Digital Input) can be expanded. Built-in 500mAh battery and support infrared (IR) transmission and reception. In order to meet the requirements of a multi-channel interface power supply at the same time, a DC power interface is provided for external power supply, the battery can be charged through the M5Core with USB-C.
Communication protocol: I2C(0x38)
Applications:
- Actuator / motor driver
- Acquisition and control of multiple input and output signals
- Infrared controller
- DIY Toy base
