Wio-E5 LoRa Wireless Module (STM32WLE5JC) – ARM Cortex-M4 MCU with SX126x Transceiver, LoRaWAN Support for EU868 & US915 -Seeed Studio

Wio-E5 LoRa Wireless Module (STM32WLE5JC) – ARM Cortex-M4 MCU with SX126x Transceiver, LoRaWAN Support for EU868 & US915 -Seeed Studio

The Wio-E5 LoRa wireless module (STM32WLE5JC) is a powerful and compact long-range communication solution designed with a Stamp Hole form factor for easy integration into your device’s mainboard.

Featuring the ARM Cortex-M4 MCU with SX126x LoRa transceiver, it supports multiple global frequency plans (EU868, US915, AU915, AS923, KR920, IN865) and is fully compatible with LoRaWAN® Class A/B/C protocols, making it suitable for diverse IoT applications.

Its pre-certified design also ensures faster time-to-market while reducing certification costs.

With built-in AT command firmware, the Wio-E5 allows beginners to prototype or deploy applications quickly using simple commands.

At the same time, advanced developers can take advantage of the SDK to build fully customized solutions.

Combining high performance, global compatibility, and ease of use, the Wio-E5 makes deploying reliable, scalable IoT systems more efficient than ever.

Features:

• High performance communication with up to 22dBm transmit power at 868/915MHz and -136.5dBm sensitivity (SF12, 125KHz BW).
• Long-distance capability supported by a 158dB link budget for extended coverage.
• Global frequency support with embedded LoRa protocol, compatible with worldwide frequency plans.
• Flexible peripheral interfaces, including UART, I2C, and ADC for easy expansion and integration.
• Developer-friendly design featuring built-in AT command firmware and SDK support for custom product development.
• Pre-certified module with FCC, CE, IC, Telec, WPC, and RCM certifications for faster deployment and compliance.
